Professional Eps Machine Manufacturer Semi-auto Eps Shape Molding Machine Eps White Lost Foam Casting Molding Machine
- Overview
- Recommended Products
Top sales semi-auto eps shape molding machine hydraulic type
Main feature:
1) The machine has an intelligent control system made of PLC programmable controller, touch screen, hydraulic pressure components and pneumatic components. 2) The machine is capable of automatic feeding, heating and cooling nd has double-speed hydraulic pressure control system 3) The machine features stable operation and accurate travel with high quality products 4) The machine saves steam and manpower, improves efficiency and is easy for operation. Each worker many simultaneously operate multiple machines
Technical data
|
Subjects
|
Unit
|
GJ-BCY-1210
|
GJ-BCY-1310
|
GJ-BCY-1513
|
GJ-BCY-1814
|
||
|
Worktable size
|
mm
|
1200×1000
|
1300×1000
|
1500×1300
|
1800×1400
|
||
|
Open mold distance
|
mm
|
1200
|
1200
|
1200
|
1200
|
||
|
Steam inlet
|
mm
|
DN40
|
DN40
|
DN40
|
DN40
|
||
|
Cooling water inlet
|
mm
|
DN40
|
DN40
|
DN50
|
DN50
|
||
|
Compressed air inlet
|
Inlet size
|
mm
|
DN25
|
DN25
|
DN25
|
DN25
|
|
|
Production cycle
|
Mould inlet
|
s/cycle
|
120---150
|
130---170
|
150---200
|
180---250
|
|
|
Installation power
|
Inlet pressure
|
kw
|
5.1
|
5.1
|
5.1
|
5.1
|
|
|
Machine weight
|
Consumption
|
kg
|
2000
|
2600
|
3400
|
4500
|
|
